Van Mark - Mark II TM-Series Contractor Siding Brake

(No reviews yet) Write a Review
SKU:
Van Mark TM-Series
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
Select Option below to see Price:
»
  • Van Mark - Mark II TM-Series Contractor Siding Brake
  • Van Mark - Mark II TM-Series Contractor Siding Brake
  • Van Mark - Mark II TM-Series Contractor Siding Brake
  • Van Mark - Mark II TM-Series Contractor Siding Brake
  • Van Mark - Mark II TM-Series Contractor Siding Brake
Price: $741.49 - $1,865.00
Frequently bought together:

Description

Van Mark - Mark II TM-Series Contractor Siding Brake


Building upon the reputation of the Mark I Series, the Mark II TrimMaster arrives with leading technologies such as the Power Lock bar & POWERslot technology for easier bending, making smaller channels and hollow core hinge extrusions for added strength. We've also left you the ability to make fine-tune adjustments to this brake, though you may never have to. Ultra High Molecular Weight (UHMW), wedges are independently adjustable and replaceable should the occasion ever arise. After all, we believe a Van Mark brake is the closest thing to a non-adjustment brake you'll find out there.

The Mark II TrimMaster Commercial brake has additional C castings to handle medium grade metals with ease. Like the Contractor, the Commercial model provides all the bending power needed without sacrificing one of the most important features in a job site brake, portability!






Model Line:
Mark II TrimMaster
Throat Depth:
14"
Hinge Type:
Stand Options:
Sold seperately; Click here for Stands
Warranty:
1 Year



CORE SPECS
Model
Length
Castings
Weight
TM2
2'0" (0.6 m)
2 ea.
36 lbs (16.4 kg)
TM4
4'6" (1.4 m)
3 ea.
67 lbs (30.5 kg)
TM6
6'6" (2.0 m)
3 ea.
85 lbs (38.6 kg)
TM8
8'6" (2.6 m)
4 ea.
104 lbs (47.3 kg)
TM10
10'6" (3.2 m)
5 ea.
123 lbs (55.9 kg)
TM12*
12'6" (3.8 m)
6 ea.
159 lbs (72.3 kg)

* dual bending & locking handles

BENDING CAPACITIES*
Material
Maximum Thickness
Aluminum (3003H14)
.032"
Galvanized Steel
26 ga.
Painted Steel (Grade D)
26 ga.
Roofing Copper
24 oz.
Zinc
.032"
Stainless Steel (304L)
26 ga.

* Capacities are based on standard metal properties for coil & sheet. Please contact our factory for capacities on your specific material.



14" Throat Depth

The 14" Throat Depth was established early on as the standard for bending needs. The typical residential trim piece is around 8" in width, which is easily done with a 14" Throat Brake. If you are still unsure if a 14" Throat Brake is right for you, look at the material you are bending. If you are primarily using 24" coil stock, then a 14" throat depth will be perfect for everyday work.

Included on:

  • Mark I Series™ Contractor
  • Mark I Series™ Residential Heavy Duty
  • Mark II TrimMaster® Contractor
  • Mark II TrimMaster® Residential Heavy Duty
  • Mark IV Industrial TrimMaster®

20" Throat Depth

The 20" casting was originally engineered to make the ultimate jobsite metal roofing brake, the Industrial Metal Master® 20. After customer demand from residential siding and roofing contractors, we created the Metal Master® 20 Residential. The immense strength of our 20" casting allowed us to include one less casting on a 10’6" compared to our Mark I Series™ and Mark II TrimMaster®.

Included on:

  • Metal Master® 20 Contractor
  • Metal Master® 20 Residential Heavy Duty
  • Industrial Metal Master® 20
