Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana

(No reviews yet) Write a Review
SKU:
PD-ERGM
Availability:
In-Stock | Ready to Install or Ship
Weight:
0.00 LBS
Shipping:
Calculated at Checkout
.:
Select Option below to see Price
  • Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana
  • Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana
  • Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana
  • Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana
  • Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana
$431.17 - $2,592.43

Description

Prime Design "ErgoRack" Drop Down Ladder Rack | Chevy Express & GMC Savana

ErgoRack / Lightweight, Safe and Easy

Prime Design has been the industry’s ergonomic leader since 1992, when we first introduced the concept of an ergonomic ladder rack.

Our design philosophy starts with the worker – how can we make the job safer, easier and more comfortable for the human body? That is because we firmly believe that a product’s design and how it impacts the user is every bit as important as the quality of materials and construction.

The ErgoRack was designed to reduce muscle stress, eliminate risk of injury and speed the job of loading and unloading ladders from a work van.



VRR-GM-M Ladder Drop Rack BOTH Sides
Vehicle GM
Model CHEVROLET EXPRESS / GMC SAVANA
Features CURBSIDE:  ROTATION
  STREETSIDE: ROTATION

PART NUMBER DESCRIPTION BOX SIZE WEIGHT
FBM-1016-BLK MOUNTING, 1996+ CHEVY EXPRESS / GMC SAVANA 25 x 9 x 4 8
CBR-0003 CROSSBAR PAIR, 68" FAMILY 63 x 5 x 2 13
FEA-0002 ROTATION NO SLIDE 36 x 15 x 6 25
FEA-0002 ROTATION NO SLIDE 36 x 15 x 6 25
FEA-0015 RH LOW ROOF DRIVE SHAFT WITH BENT HANDLE 47 x 9 x 8 19
FEA-0016 LH LOW ROOF DRIVE SHAFT WITH BENT HANDLE 47 x 9 x 8 20
FEA-0022 CONNECTING BAR, 5 FOOT 3 x 62 6
FEA-0022 CONNECTING BAR, 5 FOOT 3 x 62 6

VBR-GM-M Ladder Drop Rack CURBSIDE
Vehicle GM
Model CHEVROLET EXPRESS / GMC SAVANA
Features CURBSIDE:  ROTATION
  STREETSIDE: BASE - END STOPS

PART NUMBER DESCRIPTION BOX SIZE WEIGHT
FBM-1016-BLK MOUNTING, 1996+ CHEVY EXPRESS / GMC SAVANA 25 x 9 x 4 8
CBR-0003 CROSSBAR PAIR, 68" FAMILY 63 x 5 x 2 13
FEA-0001 END STOPS (PAIR) 7 x 6 x 5 2
FEA-0002 ROTATION NO SLIDE 36 x 15 x 6 25
FEA-0015 RH LOW ROOF DRIVE SHAFT WITH BENT HANDLE 47 x 9 x 8 19
FEA-0022 CONNECTING BAR, 5 FOOT 3 x 62 6

VRB-GM-M Ladder Drop Rack STREETSIDE
Vehicle GM
Model CHEVROLET EXPRESS / GMC SAVANA
Features CURBSIDE: BASE - END STOPS
  STREETSIDE: ROTATION

PART NUMBER DESCRIPTION BOX SIZE WEIGHT
FBM-1016-BLK MOUNTING, 1996+ CHEVY EXPRESS / GMC SAVANA 25 x 9 x 4 8
CBR-0003 CROSSBAR PAIR, 68" FAMILY 63 x 5 x 2 13
FEA-0001 END STOPS (PAIR) 7 x 6 x 5 2
FEA-0002 ROTATION NO SLIDE 36 x 15 x 6 25
FEA-0016 LH LOW ROOF DRIVE SHAFT WITH BENT HANDLE 47 x 9 x 8 20
FEA-0022 CONNECTING BAR, 5 FOOT 3 x 62 6

VBB-GM-M Ladder Rack - NO Drop Downs
Vehicle GM
Model CHEVROLET EXPRESS / GMC SAVANA
Features CURBSIDE: BASE - END STOPS
  STREETSIDE: BASE - END STOPS

PART NUMBER DESCRIPTION BOX SIZE WEIGHT
FBM-1016-BLK MOUNTING, 1996+ CHEVY EXPRESS / GMC SAVANA 25 x 9 x 4 8
CBR-0003 CROSSBAR PAIR, 68" FAMILY 63 x 5 x 2 13
FEA-0001 END STOPS (PAIR) 7 x 6 x 5 2
FEA-0001 END STOPS (PAIR) 7 x 6 x 5 2




<
